PM2000-8000 |
PM10000 | MUSIC MANAGER |
| CHANNELS | 2/4/5/6/8 | 2-10 | 4 |
| PHONO
INPUTS (ex works) Input Impedance Ohms Nominal Input Level Maximum Input Level Signal to Noise Ratio |
2/3/3/3/3
47k 2mV 10mV -80dB |
3 (Standard
version) 47k 2mV 10mV -80dB |
0 (optional) 47k 2mV 10mV -80dB |
| LINE INPUTS Input Impedance Ohms Sensitivity Maximum Input Level Equivalent Input Noise |
2/5/7/9/13
10k -26dBu 8V -84dB |
11 (Standard
version) 10k/15k -36dBu 8V -86dB |
6 10k -26dBu 8V -84dB |
| MIC INPUTS
Input Impedance Ohms (bal.) Sensitivity Maximum Input Level Equivalent Input Noise Talkover Attenuation (variable) Phantom Power |
2/4/5/6/8
2k -60dBu min. -12dBu max. -127dB - - |
2+6
2k -65dBu min. -12dBu max. -127dB 0-20dB +48V |
1+1 2k -60dBu min. -12dBu max. -127dB - - |
| EQUALIZER
Low (special) Mid (bell, Q=1,5) High (shelving) |
triple
+-12dB @ 80Hz +-12dB @ 1.5kHz +-12dB @ 12kHz |
triple
+-16dB @ 80Hz +-16dB @ 1.5kHz +-16dB @ 12kHz |
triple +-12dB @ 80Hz +-12dB @ 1.5kHz +-12dB @ 12kHz |
| OUTPUTS
Frequency Response Master (balanced) nom./max. Distortion Monitor (balanced) Zone (unbalanced) Subwoofer (balanced) Slope/Frequency Light (transformer balanced) Record/Tape (unbalanced) Headphone (6.3mm Jack) AUX 1+2 Return (unbalanced) AUX 1+2 Send (unbalanced) |
10-60000Hz
(-3dB) +6dBu/+22dBu (10V) <0.009% THD/+6dBu +6dBu/+22dBu (10V) - - - - -10dbV 1000mW/8-600 Ohms - - |
10-100000
Hz (-3dB) +4dBu/+22dBu (10V) <0.009% THD/+4dBu +4dBu/+22dBu (10V) +4dBu/+22dBu (10V) +4dBu/+22dBu (10V) -12dB/octave @ 80Hz +4dBu/+22dBu (10V) -10dbV 1000mW/8-600 Ohms +0dbU/10k Ohms +0dbU/600 Ohms |
10-60000Hz
(-3dB) +6dBu/+22dBu (10V) <0.009% THD/+6dBu +6dBu/+22dBu (10V) - - - - -10dbV 1000mW/8-600 Ohms - - |
| Overall Width
(mm) Overall Lenght (mm) Overall Height (mm) Mounting Hole Width (mm) Mounting Hole Lenght (mm) Mounting Hole Height (mm) Net Weight Shipping Weight Power Consumption Power Requirements |
293 /
406 / 483 / 483 / 483 310 / 310 / 262 / 310 / 340 90 / 90 / 90 / 90 / 90 285 / 373 / 450 / 450 / 450 285 / 285 / 230 / 285 / 295 88 / 88 / 88 / 88 / 88 4.7 / 6.0 / 6.1 / 8.0 / 8.3 5.5 / 7.0 / 7.0 / 9.5 / 10.0 20 Watts 115/230VAC ~ 50/60Hz |
483
400 160 440 365 155 12.0 13.0 50 Watts 115/230VAC ~ 50/60Hz |
483
176 90 450 146 88 5.5 6.0 20 Watts 115/230VAC ~ 50/60Hz |
| OPTIONS | K-ALPS
Faders Transformer balanced outputs |
Transformer balanced outputs | K-ALPS
Faders Transformer balanced outputs |
